1200x1200mm 250 Ton Plate Vulcanizing Press 8KW Rubber Tire Tread Making Machine

Product Categories
Qingdao Honghesheng Industry Co., Ltd.
Contact Now

1200x1200mm 250 Ton Plate Vulcanizing Press 8KW Rubber Tire Tread Making Machine

Brand Name : HHS

Model Number : XLB800-2200

Certification : CE

Place of Origin : Qingdao Shangdong

MOQ : 1 set

Price : USD 50000

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 60 sets/Year

Delivery Time : 15-30 work days

Packaging Details : Wooden cases / Containers, etc

Type : Vulcanizer

Colour : all colour

Voltage : customized

Power(W) : 11KW*2

Temperature : max 300 degree

Plates : 300-2100mm

Hot Plates Material : Q-235 material.

Heating : electricity , steam heating , conduction oil heating .

Weight : 50000 kg

Contact Now

Tire Tread Vulcanizer For Tyre Retreading / Precure Rubber Tread Making Machines

Product Description

Usage:

Strip precured tread vulcanizing press is used to produce strip precured tread for renovation of all kinds of tires. And is suitable for cold renovation procedure of tires.
We can supply strip precured tread vulcanizing press with platen size 4100*350, 4600*540, 6600*510, 4000*700, 3800*360
5500*360, 3800*700, total pressure 400t, 650t, 750t, 900t, 1100t, and other models according to the requirements of the buyer. the press can be equpped with mould moving plate per layer hot plate, it is easy to loading and discharge products.
Please contact us if you feel free.

Technical specifications:

Data/Model

XLE-Q4100X

360X5

XLE-Q550X

360X5

XLE-Q4200X

700X4

XLE-Q11000X

400X5
Total pressure (MN) 6.00 8.00 10.00 26.00
Plate size L*W (mm): 4100X360 5500X360 4200X700 11000X400
Daylight opening (mm): 200 200 200 200
Working layer: 5 5 4 5
Diameter of cylinder (mm) 250 250 360 360
Number of cylinder (sets) 6 8 5 14
Max. stroke of cylinder (mm) 800 800 800 800
Max. pressure of hydraulic system (Mpa): 20.5 21.5 20 20
Motor power (kw): 7.5 21.5 22 44
Overall size L*W*H (mm): 5470*2280*3285 7600*2700*3100 6690*2410*3345 15500X3400X4200
Weight (kg) 26000 45000 48000 132000
